quine20250104.vhdl

-- (C) David Vajda
-- Tue Apr  1 02:34:39 2025
-- 3 Network - TTL - Disjunktive Normalform


library ieee;
use ieee.std_logic_1164.all;

entity quine20250401 is
port (
	x2, x1, x0: in std_logic;
	y: out std_logic
);
end;

architecture behaviour of quine20250401 is
begin
	y	<=	x1;
end;

library ieee;
use ieee.std_logic_1164.all;

entity quine20250401testbench is
port (
	y: out std_logic
);
end;

architecture behaviour of quine20250401testbench is
	component quine20250401
	port (
		x2, x1, x0: in std_logic;
		y: out std_logic
	);
	end component;
	signal x2, x1, x0: std_logic;
begin
	q: quine20250401 PORT MAP (x2=>x2, x1=>x1, x0=>x0, y=>y);
	x0 <= '0' after 0 ns, '1' after 10 ns, '0' after 20 ns, '1' after 30 ns, '0' after 40 ns, '1' after 50 ns, '0' after 60 ns, '1' after 70 ns, '0' after 80 ns;

	x1 <= '0' after 0 ns, '0' after 10 ns, '1' after 20 ns, '1' after 30 ns, '0' after 40 ns, '0' after 50 ns, '1' after 60 ns, '1' after 70 ns, '0' after 80 ns;

	x2 <= '0' after 0 ns, '0' after 10 ns, '0' after 20 ns, '0' after 30 ns, '1' after 40 ns, '1' after 50 ns, '1' after 60 ns, '1' after 70 ns, '0' after 80 ns;
end;
