automat20241130.txt

(C) David Vajda
Klassisches Schaltwerk - binär und unär kodiert
2024-11-30

	b a x	b a y
0	0 0 0	1 1 0
1	0 0 1	1 0 0
2	0 1 0	0 0 0
3	0 1 1	1 1 1
4	1 0 0	0 0 1
5	1 0 1	1 0 0
6	1 1 0	1 1 1
7	1 1 1	0 0 1


	b a x	b
0	0 0 0	1
1	0 0 1	1
2	0 1 0	0
3	0 1 1	1
4	1 0 0	0
5	1 0 1	1
6	1 1 0	1
7	1 1 1	0

	b a x	a
0	0 0 0	1
1	0 0 1	0
2	0 1 0	0
3	0 1 1	1
4	1 0 0	0
5	1 0 1	0
6	1 1 0	1
7	1 1 1	0

	b a x	y
0	0 0 0	0
1	0 0 1	0
2	0 1 0	0
3	0 1 1	1
4	1 0 0	1
5	1 0 1	0
6	1 1 0	1
7	1 1 1	1


	b a x	b
0	0 0 0	1
1	0 0 1	1
3	0 1 1	1
5	1 0 1	1
6	1 1 0	1

	b a x	a
0	0 0 0	1
3	0 1 1	1
6	1 1 0	1

	b a x	y
3	0 1 1	1
4	1 0 0	1
6	1 1 0	1
7	1 1 1	1



	b a x	b
Gruppe 0:
0	0 0 0	1
Gruppe 1:
1	0 0 1	1
Gruppe 2:
3	0 1 1	1
5	1 0 1	1
6	1 1 0	1

	b a x	a
Gruppe 0:
0	0 0 0	1
Gruppe 2:
3	0 1 1	1
6	1 1 0	1

	b a x	y
Gruppe 1:
4	1 0 0	1
Gruppe 2:
3	0 1 1	1
6	1 1 0	1
Gruppe 3:
7	1 1 1	1



b a x	b
Gruppe 0:
0	0 0 0	1
Gruppe 1:
1	0 0 1	1
Gruppe 2:
3	0 1 1	1
5	1 0 1	1
6	1 1 0	1

0:1			0	0	-
1:3			0	-	1
1:5			-	0	1
6			1	1	0

	b	<=	(not b and not a) or
				(not b and x) or
				(not a and x) or
				(b and a and x);

	b a x	a
Gruppe 0:
0	0 0 0	1
Gruppe 2:
3	0 1 1	1
6	1 1 0	1

	a	<=	(not b and not a and not x) or
			(not b and a and x) or
			(b and a and not x);

	b a x	y
Gruppe 1:
4	1 0 0	1
Gruppe 2:
3	0 1 1	1
6	1 1 0	1
Gruppe 3:
7	1 1 1	1

4:6			1	-	0
3:7			-	1	1
6:7			1	1	-

		3	4	6	7
4:6			+	+
3:7		+			+
6:7				+	+

4:6			1	-	0
3:7			-	1	1


	y	<=	(b and not x) or
			(a and x);


	b	<=	(not b and not a) or
				(not b and x) or
				(not a and x) or
				(b and a and x);
	a	<=	(not b and not a and not x) or
			(not b and a and x) or
			(b and a and not x);
	y	<=	(b and not x) or
			(a and x);


	b a x	b a y
0	0 0 0	1 1 0
1	0 0 1	1 0 0
2	0 1 0	0 0 0
3	0 1 1	1 1 1
4	1 0 0	0 0 1
5	1 0 1	1 0 0
6	1 1 0	1 1 1
7	1 1 1	0 0 1

unär kodiert

Zustand		Eingabe		Ausgabe		Folgezustand	CodeFolgezustand
													z3+ z2+ z1+ z0+
z0			0			0			z3				1	0	0	0
z0			1			0			z2				0	1	0	0
z1			0			0			z0				0	0	0	1
z1			1			1			z3				1	0	0	0
z2			0			1			z0				0	0	0	1
z2			1			0			z2				0	1	0	0
z3			0			1			z3				1	0	0	0
z3			1			1			z3				1	0	0	0


z0+	<=	z0 and not x or z1 and x or z3
z1+	<=	z1 and not x or z2 not x
z2+	<=	z0 and x or z2 and x

y	<=	(z1 and x) or (z2 and not x) or z3
